Product Description
Hydraulic In-Feed / Thru- Feed Type
Thread Rolling Machine NRS-18T
Hydraulic indeed Thru Feed Type Thread Rolling Machine NRS-18T Features:
Name Specification | ITEM | NRS-18T |
Range of thread | Max.diameter | Ф60 mm |
Min.diameter | Ф6mm | |
Pitch | 0.6-4mm | |
Range of length(in feed) | 5-150mm | |
Range of length(thru feed) | Free | |
Speed Range | 0-50 R.P.M | |
Thread rolling Dies | Max.diameter | Ф178mm |
Bore diameter | ф54mm (Changeable Axis) | |
Width range | 50-150mm | |
Key way | 12mm | |
Dies spindle | Max.diameter | 190mm |
Min.diameter | 130mm | |
Maximum rolling pressure | Max rolling pressure | 18Tons |
Roller drive horsepower | Main power | 10HP(7.5kw) |
Hydraulic system horsepower | Hydraulic power | 3HP(2.2kw) |
Cooling pump horsepower | Coolant power | 1/4HP(0.18kw) |
Height from ground to roller center | Height from Floor to Spindle center | 1000mm |
cover an area | Floor Speace Required(LxWxH)m/m | 1660x1550x1700mm |
Weight | Net weight | 2100kgs |
Gross weight | 2500kgs |
