SPECIFICATIONS:
| Model | SC-310 |
| Rolling dia. | 2~14mm |
| Pitch | 0.4~2.0 P |
| Rolling length | In-feed ： 28mm (Length) / Thru-feed (Free) Any length |
| Mainspindle motor | 2 HP/6P |
| Hyd. pump motor | 2 HP |
| Coolant pump motor | 1/8 HP |
| Rolling spindle dia. | 50.5mm |
| Rolling dies dia. | 100mm |
| Rolling dies thickness | 30mm(Standar) / 40mm(Max) |
| Distance between spindle centers | 90~120mm |
| Rev. speed of rolling dies | 95/170/270/375 rpm |
| Processing capacity | 20~40 pcs/min |
| Hyd. feeding pressure | 4 Tons (80Kg/cm2) |
| Ht. from table surface to center of rolling dies | 85mm |
| N.W. /G.W. | 615kg/760kg |
| Machine size | 1300x1020x770mm |
| Measurement | 1380x1500x1220mm |
※The specification & dimension are subjected to change without prior notice.
※Machine made available on customer's request.
